Mã hàng | Cỡ nòng Hút/ đẩy (mm) | Công suất (HP) | 50Hz | 60Hz | Khối lượng (Kg) | ||
Lưu lượng max (l/min) | Cột áp max (mAq) | Lưu lượng max (l/min) | Cột áp max (mAq) | ||||
SM 400H | 40x40 | 1/2HP, 3Phase, 380v, 2Pole | 280 | 9.5 | 275 | 10.5 | 20 |
SM 401H | 40x40 | 1HP, 3Phase, 380v, 2Pole | 320 | 15 | 340 | 16 | 24 |
SM 402L | 50x40 | 2HP, 3Phase, 380v, 2Pole | 390 | 16.5 | 380 | 18.5 | 37 |
SM 402H | 50x40 | 2HP, 3Phase, 380v, 2Pole | 400 | 20 | 485 | 23 | 37 |
SM 502L | 50x50 | 2HP, 3Phase, 380v, 2Pole | 430 | 17.5 | 420 | 18 | 37 |
SM 502H | 50x50 | 2HP, 3Phase, 380v, 2Pole | 410 | 20 | 510 | 22.5 | 37 |
SM 403L | 50x40 | 3HP, 3Phase, 380v, 2Pole | 450 | 18 | 500 | 20.5 | 40 |
SM 403H | 50x40 | 3HP, 3Phase, 380v, 2Pole | 440 | 23 | 540 | 29.5 | 40 |
SM 503L | 50x50 | 3HP, 3Phase, 380v, 2Pole | 515 | 20.5 | 530 | 20 | 40 |
SM 503H | 50x50 | 3HP, 3Phase, 380v, 2Pole | 440 | 18.5 | 560 | 29.5 | 40 |
SM 603L | 65x50 | 3HP, 3Phase, 380v, 2Pole | 400 | 28 | 420 | 31 | 40 |
SM 653L | 65x65 | 3HP, 3Phase, 380v, 2Pole | 720 | 22 | 800 | 19.5 | 40 |
SM 505H | 50x50 | 5HP, 3Phase, 380v, 2Pole | 590 | 29 | 650 | 40 | 54 |
SM 605L | 65x50 | 5HP, 3Phase, 380v, 2Pole | 530 | 31 | 560 | 34.5 | 54 |
SM 655L | 65x65 | 5HP, 3Phase, 380v, 2Pole | 900 | 23 | 850 | 31 | 52 |
SM 401L | 50x40 | 1HP, 3Phase, 380v, 4Pole | 300 | 8 | 300 | 13 | 24 |
SM 501L | 50x50 | 1HP, 3Phase, 380v, 4Pole | 300 | 8.5 | 290 | 13 | 37 |
SM 652L | 65x65 | 2HP, 3Phase, 380v, 4Pole | 350 | 7 | 450 | 9.7 | 38 |
